Stable structure
Stable structure with fixed installation and excellent wind resistance
High brightness
High brightness, ensuring clear visibility under strong sunlight
Superior sealing technology
Superior sealing technology, dustproof, waterproof and anti-corrosion
Excellent protection capability
High protection grade, adaptable to harsh outdoor conditions including sunlight, rain and temperature changes
Convenient inspection and repair
Supports front and rear maintenance
|
Product
|
XT-297
|
XT-391
|
XT-481
|
XT-625
|
XT-781
|
XT-1040
|
|
Pixel Pitch
|
2.97
|
3.91
|
4.81
|
6.25
|
7.81
|
10.4
|
|
Cabinet Resolution(W×H)
|
336×336
|
256×256
|
208×208
|
160×160
|
128×128
|
96×96
|
|
Brightness(cd/m²)
|
4000~4500
|
4000~4500
|
4000~4500
|
4000~4500
|
4500~5500
|
4500~5500
|
|
Scan method
|
1/21s
|
1/16s
|
1/13s
|
1/10s
|
1/4s
|
1/2s
|
|
Cabinet Size(mm)
|
1000×1000×91
|
|
Visual Angle(H/V)
|
120°/120°
|
|
IP Rating
|
IP65
|
|
Refreshing Ratio(Hz)
|
≥3840
|
|
Grey Level
|
≥14
|
|
Average Power Consumption(W/m2)
|
300～560
|
